Reliable chassis and efficient operation: Equipped with shuttle-type shift chassis, all chassis parts are from high-quality suppliers in the industry, with good agronomic adaptability and higher operating efficiency;
Strong powe: Equipped with a large-bore self-priming/supercharged engine; good power performance, large torque reserve, low noise, and greater traction/lifting force;
Comfortable driving: The new optimized cab design has large space, good vision, and optional rear-view image to observe the surrounding environment without blind spots, making driving safer;
Strong agronomic adaptability: It can meet various wheelbases and agronomic operation requirements by adjusting the configuration;
High reliability: High-strength transmission system, large traction wet brake, good reliability;
Value-added service: The main parts of the whole machine are guaranteed for 18 months, and the “Wangke service” makes your car worry-free.
| Parameter | LT-504/604 Specification |
| Dimensions (L×W×H) | 3300×1500×1970 mm |
| Travel Speed | 2.2–32 km/h |
| Diesel Engine Brand | Quanchai / Huafeng / Laidong engines |
| Working Speed | Approx. 6–8 mu/hour |
| Total Weight | 1600 kg |
| Air Filter | Dry type |
| Fuel Consumption | 6 L/hour |
| Radiator Type | Water cooling |
| Transmission Type | Direct gear drive |
| Gearbox | Custom pure gear type with heavy-duty gearbox |
| Rated Power | 36.8 kW |
| Engine Air Intake | Natural aspiration |
| Rear Axle | TYE large axle (half shaft thickened to 60 mm) |
| Minimum Ground Clearance | 300 mm (front axle bottom) |
| Gear Configuration | 8 forward + 8 reverse |
| PTO Standard Speed | 540–720 rpm |
| Front Tires | 650-16 / 750-16 (optional sizes) |
| Track Width | Front: 1.4 m, adjustable 1.2 m; Rear: 1.5 m, adjustable 1.2 m |
| Rear Tires | 11.2-24 / 11.2-28 (optional sizes) |
| Compatible Implements | Seeders, harvesters, rotary tillers, furrowers, trenchers, sprayers, engineering trailers, etc. |
The equipment combines high performance and adaptability, integrating intelligent loading and unloading technology to efficiently improve the automation efficiency of operations and material handling, and is suitable for a variety of application scenarios.
